Planetary Gearhead 28mm

Buy Ruixing Planetary Gearhead 28mm which is of high quality directly with low price. And we will offer you the best after-sale service and timely delivery.

Send Inquiry

Product Description

Buy Ruixing Planetary Gearhead 28mm which is of high quality directly with low price. And we will offer you the best after-sale service and timely delivery. Planetary gearheads have several advantages, such as high torque output, low backlash, and high efficiency. They are ideal for use in a variety of applications, including robotics, medical devices, automotive and aerospace components, precision machinery, and camera gimbals. In summary, a 28mm planetary gearhead is a highly effective gearbox that can provide precise motion control and high torque output in small electric motors and other precision applications.



P28H Technique Parameter

Technical Parameter


Technical Parameter
Gearbox Diameter mm 27.6/26
Bearing of Shaft optional/- Ball Bearing
Radial Clearance mm ≤0.1
Axial Clearance mm ≤0.2
Permission Input Speed rpm ≤10,000
Recommended Temperature Range -20 to +125
Permission Installation Force N ≤100
Axial Load N ≤50
Radial Load N ≤50
Typical Applications
Medical device Digital products UAV Industrial automation
product information
1 Stage 1 2 3
4
5
2 Number of Order 1228001 1228005 1228015 1228022 1228036 1228050 1228072 1228098
3 Ratio 3.57 12.76 45.55 73.60 182.22 338.56 728.86 1557.38
4 Number of Order 1228002 1228007 1228016 1228025 1228037 1228056 1228074 1228707
5 Ratio 4.00 16.00 51.02 84.64 204.08 404.80 816.33 1936.00
6 Number of Order 1228004 1228009 1228018 1228029 1228043 1228060 1228081 1228113
7 Ratio 5.50 18.40 58.67 101.20 262.86 465.52 1024.00 2286.04
8 Number of Order
1228012 1228019 1228032 1228047 1228064 1228087 1228117
9 Ratio
22.00 64.00 121.00 302.29 556.60 1209.14 2662.00
1 L(mm) 26.7 31.2 35.7
40.2 44.7
2 Torque(Nm) 0.5 1 3
4 4
3 Stall Torque(Nm) 0.8 2 4
5 5
4 Max Efficiency(%) 90 81 73
65 59
5 Weight(g) 50.0 65.0 85.0
95.0 110.0
6 No-Load Backlash(°) 1 1.5 1.5
2 2

MEASUREMENT
