Planetary Gearhead 22mm

You are welcomed to come to our factory to buy the latest selling, low price, and high-quality Ruixing Planetary Gearhead 22mm. We look forward to cooperating with you.

Send Inquiry

Product Description


You are welcomed to come to our factory to buy the latest selling, low price, and high-quality Ruixing Planetary Gearhead 22mm. We look forward to cooperating with you.Some advantages of a planetary gearhead include: High torque: Planetary gearheads are designed to provide high torque output in a compact package, making them ideal for small motors and other precision applications. Low backlash: Planetary gearheads have low backlash, which means there is minimal play between the gears and the output shaft, resulting in more precise motion control. High efficiency: Planetary gearheads can achieve high efficiency, which means less energy is wasted as heat.

P22H Technique Parameter

Technical Parameter


Gearbox Diameter mm 22
Bearing of Shaft optional/- Sliding Bearing/Ball Bearing
Radial Clearance mm ≤0.1
Axial Clearance mm ≤0.2
Permission Input Speed rpm ≤10,000
Recommended Temperature Range -20 to +125
Permission Installation Force N ≤100
Axial Load N ≤50
Radial Load N ≤50
Typical Applications
Medical device Digital products UAV Industrial automation
product information
1 Stage 1 2 3 4 5
2 Number of Order 1220001 1220005 1220015 1220022 1220036 1220050 1220072 1220098
3 Ratio 3.57 12.76 45.55 73.6 182.22 338.56 728.86 1557.38
4 Number of Order 1220002 1220007 1220016 1220025 1220037 1220056 1220074 1220107
5 Ratio 4 16 51.02 84.64 204.08 404.8 816.33 1936.00
6 Number of Order 1220004 1220009 1220018 1220029 1220043 1220060 1220081 1220113
7 Ratio 5.5 18.4 58.67 101.20 262.86 465.52 1024.00 2286.04
8 Number of Order
1220012 1220019 1220032 1220047 1220064 1220087 1220117
9 Ratio
22 64.00 121.00 302.29 556.60 1209.14 2662.00
1 L (mm) 22.1 25.9 29.7 33.5 37.3
2 Torque (Nm) 0.3 0.3 0.5 0.5 0.75
3 Stall Torque (Nm) 0.5 0.5 0.8 0.8 1
4 Max Efficiency (%) 90 81 73 65 59
5 Weight (g) 30.0 35.0 46.0 55.0 65.0
6 No-Load Backlash (°) 1 1.5 1.5 2 2

MEASUREMENT
